3 Pack Green Blinking 5mm LED Diodes – Clear Round Lens

Bright, Efficient, and Easy-to-Use Blinking LEDs

These green blinking LED diodes are perfect for DIY electronics, indicators, hobby projects, or professional applications. Each LED features a 5mm clear round lens with a built-in blinking function, giving you reliable performance and low energy consumption in a compact design.

Key Features of the 5mm Green Blinking LED

• Built-In Blinking Effect: Flashes automatically at 1.5Hz without additional circuitry.
• Energy Efficient: Operates on just 0.06 watts, keeping power consumption low.
• High Brightness: Up to +20% brighter with a wavelength of 520–525nm for vivid green light output.
• Durable Design: 29mm long leads make soldering and installation convenient.
• Clear Round Lens: Standard 5mm package with a focused 30° viewing angle.

Technical Specifications

• Package Quantity: 3 pcs LEDs
• Lens Type: 5mm clear round
• Blinking Frequency: 1.5Hz
• Operating Voltage: DC 3.0V – 3.2V
• Forward Current: IF = 20mA
• Wattage: 0.06W per LED
• Number of Pins: 2-pin DIP LEDs
• Wavelength: 520nm – 525nm
• Viewing Angle: 30°
• Weight: Approx. 0.29g per LED

Suggested Operation

For DC 6–12V circuits, use a 430Ω 1/4W resistor per LED for safe operation. These LEDs are designed for low energy consumption and low heat output, making them reliable and long-lasting in various applications.

Soldering & Storage Guidelines

• Manual Soldering: Less than 3 seconds at 482°F–527°F
• Reflow Soldering: Less than 5 seconds at 500°F
• Storage: Keep in a dry environment, away from fire or high temperatures

These green blinking 5mm LEDs are versatile and built to industry-standard specifications, making them ideal for electronics projects, replacements, or educational use.
