Neutrik XLR Female 3 Pin Panel Mount Connector Silver - D-Size Metal Chassis

Reliable XLR Panel Mount Connector for Audio Projects

This 3-pin female XLR panel mount connector is a dependable solution for audio connections in DIY builds, repairs, and professional equipment. Designed in a standard D-size chassis format, this XLR connector fits most common panel cutouts, making installation simple and consistent across a wide range of audio gear.

Whether you're wiring a microphone input, building a custom audio panel, or replacing a worn connector, this XLR female panel mount provides a solid, noise-resistant connection you can trust.

Durable Metal XLR Chassis Connector Design

Built with a rugged zinc diecast housing and nickel plating, this panel mount XLR jack is designed for long-term durability. The latch locking system ensures a secure connection that won’t easily disconnect during use, making it ideal for live sound, studio setups, and installed audio systems.

The solder cup contacts allow for strong, permanent wiring connections, supporting wire sizes up to 14 AWG (2.5 mm²).

Clean Signal Performance for Audio Applications

This XLR audio panel connector is engineered for reliable signal transmission with low resistance and strong insulation characteristics. It helps maintain clean audio signals in both balanced and unbalanced configurations.

• Contact resistance: ≤ 5 mΩ
• Capacitance between contacts: ≤ 4 pF
• Insulation resistance: > 2 GΩ (initial)
• Dielectric strength: 1.5 kVdc

Easy Installation - Standard D-Size XLR Panel Mount

The universal D-size metal body makes this XLR chassis connector compatible with a wide variety of panels, enclosures, and rack equipment. With a smooth insertion and withdrawal force (≤ 20 N), connections are easy to make while still remaining secure.

• Connection type: XLR
• Gender: Female
• Chassis shape: D-size
• Wiring: Solder contacts
• Locking device: Latch lock

High-Quality Materials for Long Service Life

This XLR panel mount connector is built using quality materials to ensure consistent performance over time. With a lifetime rating of over 1,000 mating cycles, it is well-suited for both permanent installations and repeated use environments.

• Contacts: Bronze (CuSn8)
• Contact plating: 2 µm silver over 2 µm nickel
• Insert material: Polyamide (PA 6.6, 30% glass reinforced)
• Shell: Zinc diecast with nickel plating
• Locking element: Steel with nickel plating

Electrical Ratings and Environmental Specifications

This XLR female panel mount connector meets recognized industry standards and performs reliably across a wide range of conditions.

• Rated current per contact: 16 A
• Rated voltage: < 50 V
• Temperature range: -30 °C to +80 °C
• Protection class: IP40
• Flammability rating: UL 94 HB
• Standard compliance: IEC 61076-2-103
• Approvals: UL recognized component

Versatile XLR Connector for Everyday Use

Commonly used in microphone inputs, audio interfaces, mixers, and custom panels, this 3-pin XLR female connector is a go-to choice for both hobbyists and professionals. Its combination of durability, ease of installation, and reliable electrical performance makes it a strong fit for nearly any audio wiring project.

Model: NC3FD-L-1
