SPST Ball Cap Toggle Switch – Double Insulated, With Wire Leads, On-Off, 6A

Easy-to-Use SPST Ball Cap Toggle Switch for Everyday Projects

Upgrade your next DIY or electronics project with our SPST ball cap toggle switch. This user-friendly, double-insulated toggle switch is perfect for hobbyists, home repairs, and light-duty applications. The low-profile design features a unique ball cap handle for easy operation, offering a comfortable grip and modern look.

Key Features: Reliable On-Off Performance

• SPST (Single Pole Single Throw) circuitry: Simple on-off controls
• Rated for 6A at 125VAC and 3A at 250VAC – supports most home and workshop tasks
• Double-insulated ball cap actuator keeps you protected
• Integrated 6-inch 18AWG wire leads (side-mounted): Hassle-free and secure installation
• Low profile: 1.02" L x 0.53" W x 0.53" H
• Fits panels up to 0.33” thick (mounting hole size: 15/32")
• Modern, attractive “ball cap” toggle handle design

How to Install Your Double Insulated Toggle Switch

This on-off toggle switch 6A installs easily on panels or project enclosures – just drill a 15/32" hole and connect the color-coded 18AWG wire leads directly. No soldering needed! The double-insulated ball cap toggle handle provides extra safety and a stylish appearance, making it ideal for visible mounting on control panels, vehicles, household equipment, and more.

Applications & Compatibility

• LED lighting, model railroads, and hobby projects
• Automotive and marine electrical panels
• Home appliances, fans, and light-duty workshop equipment
• General electronics repairs and custom builds

Product Specifications

• Switch Type: SPST (Single Pole, Single Throw)
• Action: ON - OFF
• Circuitry: SPST
• Handle Style: Bat Handle / Ball Cap
• Current Rating: 6A @ 125VAC / 3A @ 250VAC
• Terminal Type: 6" 18AWG Wire Leads (side mounted)
• Mounting Hole Size: 15/32"
• Max Panel Thickness: 0.33"
• Dimensions: 1.02" L x 0.53" W x 0.53" H
• Quantity: 1 Switch
• Hillman Item Number: 884439

Notes & Warnings

• Always check current and voltage ratings before use to avoid damage.
• For indoor or protected environments – not designed for harsh outdoor exposure without additional sealing.
• This product comes individually packaged; QTY 1 per order.

Looking for a reliable, stylish, and easy-to-install electrical toggle switch? This ball cap toggle switch with wire leads is an ideal choice for everyday users. Find yours today at Vetco Electronics!
