8 Position Phoenix Connector Jack – PCB Mount

Reliable 8 Position PCB Mount Phoenix Connector

Upgrade your electronic projects with this 8 position Phoenix connector jack, designed for easy and secure PCB mounting. Also known as a Euro-Mag terminal block or Euro terminal block, this versatile connector allows you to plug and unplug wire groups without tools—making it perfect for both DIY electronics and home improvement needs.

Easy-to-Use Phoenix Connector Jack for Your Projects

This pluggable terminal strip socket (Philmore 13-2808) mates perfectly with compatible Phoenix connector terminal plugs, letting you build, repair, or expand circuits effortlessly. The horizontal, 90° design keeps the connector parallel to your circuit board for a clean, professional installation.

8 Position Terminal Block – Designed for PCB Mounting

• 8 position PCB terminal block, horizontal/90° orientation
• Mates with standard Phoenix connector plugs for flexible connections
• PCB mount with 0.2" (5.08mm) pin spacing – compatible with 0.1" protoboards
• No tools needed to insert or remove wires—ideal for fast changes

Technical Specifications

• Manufacturer: Philmore
• Manufacturer Part Number: 13-2808
• Current Rating: 15A @ 300V
• Certifications: UL Listed & CSA Certified
• Pin Spacing: 0.2" (5.08mm)
• Contact Material: Tin Plated Brass
• Housing Material: Type 6/6 Polymide 94VO
• Recommended PCB Hole Size: 0.055" (1.4mm) – use #55 drill bit
• Operating Temperature Range: -40°C (-40°F) to 105°C (221°F)

Why Choose This PCB Mount Phoenix Connector?

Whether you’re working on hobby electronics, home automation, or small repairs, this 8 position PCB mount Phoenix connector jack gives you a dependable way to organize and connect multiple wires. The pluggable terminal design means wiring changes are quick and simple, while the sturdy construction ensures a long-lasting, secure connection every time.
