12 Position Phoenix Connector Plug – 12-22 AWG, 15A

Easy-to-Use 12 Position Connector Plug for Secure Wiring

Upgrade your electronics projects or home wiring with this 12 position Phoenix connector plug. Designed for everyday convenience, this pluggable terminal block allows you to connect or disconnect multiple wires quickly and securely—no special tools needed.

Trusted Phoenix Connector Style for Reliable Connections

This Phoenix connector plug accepts wire sizes from 12 AWG to 22 AWG, making it perfect for a wide range of applications. The compression screw terminals use a simple slot-drive screw on top for easy tightening, giving you a strong, reliable hold. Each plug is rated for 15A at 300V, ensuring safe performance for your home or hobbyist projects.

Perfect Fit and Versatile Design

The right-angle (90°) design makes wiring in tight spaces easier, allowing the wire entry and plug connector to stay neat and organized. This 12 position terminal block mates with our Phoenix connector style sockets and jacks, making it great for expanding current setups or creating new connections on PCBs, control panels, or other electronic builds.

Key Features & Technical Specifications

• Number of Positions: 12
• Wire Size: 12 AWG – 22 AWG
• Maximum Current: 15A
• Voltage Rating: 300V
• Terminal Type: Slot-drive compression screw terminals
• Connector Orientation: 90° right-angle (horizontal)
• Center Spacing: 0.2" (5.08 mm) – fits 0.1" spaced protoboards
• Contact Material: Tin plated brass
• Housing Material: Type 6/6 Polyamide, 94V-0 rated
• Screw Size: 3mm x 5mm, zinc plated steel
• Operating Temperature: Max 105°C (221°F), Min -40°C (-40°F)
• Certifications: UL Listed & CSA Certified
• Also Known As: Euro Terminal Block, Euro-Mag Terminal Block
• Manufacturer: Philmore
• Manufacturer Part Number: 13-2612

Why Choose a 12 Position Phoenix Connector Plug?

If you want safe, secure, and easy-to-manage wire connections, this 12 position Phoenix connector plug is an excellent choice. Great for electronics projects, home wiring setups, or small industrial control panels, this connector provides reliable performance and flexible compatibility—all in a compact, user-friendly format.

Order Your 12 Position Phoenix Connector Plug Today

Discover how easy and secure wiring can be. Shop now for your 12 position Phoenix connector plug and make your next electrical project simple and safe.
